SPECIFICATIONS

carburetor PZ19

engine Brand FH

engine 110cc Air cooled, Fully automatic

Engine Gear Fully automatic

Transmission Chain Drive

Engine Bore X Stroke 52.4×49.5mm

compression ratio 9：1

max power 6.7HP/7500r/min

Max torque 7.2N.m/7500 r/min

Ignition CDI

Engine Oil total capacity 0.24 Gallon

Fuel Tank Capacity 0.85 Gallon

Start way Electrical Start

Front wheel 60/100-14

Rear wheel 80/100-12

Drive train Chain drive

Front absorber 320mm Non-Adjustable

Rear absorber 260mm Non-Adjustable

Front Hand Brake Hydraulic Disc

Rear Foot Brake Hydraulic Disc

Frame Single beam Heavy Duty Steel fram

N.W: 142 LBS

G.W 160 LBS

Products size(L*W*H) 61*30*35 inches

seat high 30 inches

Ground Clearance 8 inches

box size(L*W*H) 49*15*25.6inches
