SPECIFICATIONS

Size: L×W×H 2120×1140×1270mm

Wheelbase 1215 mm

Ground clearance 183 mm

Dry weight 295kg

Fuel Tank Capacity 14 L

Max speed >60 km/h

Drive System Type 2WD/4WD

Specification of tire Front: AT24×8-12

Rear: AT24×11-10

Brake system model Front: Hydraulic Disc

Rear: Hydraulic Disc

Suspension type Front:McPherson independent suspension

Rear:Swing arm

Engine model LH173MN

Engine type Single cylinder,4 stroke, water cooled

Engine displacement 275 cc

Bore and Stroke 72.5×66.8 mm

Max power 16/6500~7000 (kw/r/min)

Horse power 21.4 hp

Max torque 23/5500 (Nm/r/min)

Compression Ratio 9.5:1

Fuel system EFI

Start type Electric starting

Transmission H-L-N-R

40'HQ QTY 30 Units
