**Also available in Electric model w/ Lead Acid batteries or with Lithium batteries

SPECIFICATIONS

Vehicle dimension (L×W×H): 2843*1340*1870/ 112*52.8*73.6Inch

Dry weight: 357KG/785.4LBS

Wheelbase: 1840mm/72.4 Inch

Front Tread: 1120mm/44 Inch

Rear Tread: 975mm/38.4 Inch

Front axle loading: 135KG/297Lbs

Rear axle loading: 222KG/488.4Lbs

Top speed: 41KM/H or 25miles /H

Maxi Climbing angles: 15°

Steering radius: 3.6m/141.7 Inch

Loading capacity: 23units/40HQ

Front & Rear tire size: 24 x 8-12 Inch

Ground clearance: 155mm/6.1 Inch

Steering angle: Inner 29°, Outer 26.6°

Fuel capacity: 23L/5.06 Gallon

Suspension Front: Double A-Arm Independent Shock

Suspension Rear: Single shock swing arm

Front suspension travel: 110mm/4.3 Inch

Rear suspension travel: 100mm/3.9 Inch

Brake system: Hydraulic Disc

Parking system: Mechanical parking

Final Drive: Chain-drive

Battery information: 12V 9Ah

Ignition system: C.D.I

Engine type: 4-stroke, Single-Cylinder, Oil-cooled

Displacement: 169cc or 289cc

Max power: 7.2kw(7500r/min) /9.65HP (7500r/min) or 21kw/8500r/min

Max torque: 11.4N.m/4500 RPM or 26.5N.m/5500r/min
