Technical specification

1) Engine type: Single Cylinder, 4 Stroke, Air-Cooled, horizontal type

2) Displacement(ml): 168.9cc

3) Max Power(kw/r/min): 8.3 /8000

4) Max Torque(N.m/r/min): 11 /6000

5) Ignition system: CDI

6) Gear : CVT

7) Fuel tank capacity(L): 12

8) Economical oil exhaust(L/100km): 3.5

9) Max speed(km/h): ≥95

10) Transmission: Belt Drive

11) Brake Type(front / rear): Disc Brake / Disc Brake

12) Wheelbase(mm): 1480

13) Ground clearance(mm): 145

14) Tires (front / rear): 120/70-14 / 140/60-14

15) N. W.(kg): 117 G. W. (kg): 147

16) Product dimension(mm): 2090*730*1140

17) Carton dimension(mm): 2100*575*1120

18）Qty/40HQ: 44 PCS
